Beskrivning
Art.nr: 165301065
Ett riktigt högklassigt försteg för att matcha Cayins monoblock, eller något annat slutsteg. Genomgående mycket hög komponentkvalitet. 4 ingångar och 2 utgångar och tillhörande fjärrkontroll.
Features:
The SC-6LS MK2 adopts a new design and uses high-end components such as imported tubes, coupling capacitors, and carbon film resistors. Overall performance and sound performance have improved significantly.
Russian 12AU7 EH x2 vacuum tube used as a linear amplifier circuit
U.S. RCA 22DE4 x4 rectifiers for rectifier circuits
US Multicap Coupling Capacitors
Japan TAKMAN carbon film resistor
Whole system 15dB gain design
Custom EI type power transformer
Specification:
Output voltage: 2V (22V Max)
Frequency response. 5Hz - 100kHz (-1dB)
Harmonic distortion: 0.4% (1kHz)
Input sensitivity: 350mV
Input impedance: 100 kohms
Output impedance: 3 kohms
Power: 45W
Signal to noise ratio: 95dB
Gain: 15dB (1kHz)
Vacuum tube: 12AU7(EH) × 4, 22ED4 × 2
Input terminals: l, 2, 3, 4
Output Terminals: 4ohms, 8ohms
Dimensions: 286mm W × 328mm D × 193mm H
Net weight: 12.5kg
Gross weight: 15kg
