Chord Electronics - Symphonic - RIAA förstärkare

En högklassig RIAA förstärkare, dedikerad för MC pickuper. Reglerbar gain mellan 40-80 dB samt impedansmatchning för din MC pickup. Både balanserat och RCA på både in- och utgångarna. Supertyst, och riktigt, riktigt bra. Input Noise: 1.5nV/Hz Max Output Voltage RMS: 10v Equalisation Range: 12Hz to 25kHz Equalisation Response: RIAA Curve Equalisation Accuracy: +/- 0.1dB Frequency Response: 5Hz – 40kHz Rumble Filter: Rausch Slope -24dB per octave below 50Hz Output Impedance: 520Ω (resistive) Output Drive: Can drive 600Ω at 50% output Input Power Supply: 50v AC – 260v AC – auto adjust 50Hz – 60Hz Dimensions (including connectors): 333.5mm (W) x 59mm (H) x 142mm (D) Weight: 6kg Selectable Impedance: 4.7Ω, 33Ω, 100Ω Selectable Gain: 40dB – 80dB Inputs: 1x Stereo Balanced XLR Pair 1x Stereo Unbalanced RCA Pair Outputs: 1x Stereo Balanced XLR Pair 1x Stereo Unbalanced RCA Pair Nestling in the Choral range, the Symphonic is our flagship MC phono stage, offering a range of advanced features over the entry-level Dual. The high-performance Symphonic uses our latest high-frequency power supply technology to exploit vinyl’s full potential, along with many new key features, to bring the performance levels in line with the Choral range, home of the DAVE DAC/preamp. The Symphonic offers an almost infinite number of input impedance and gain options as well as balanced and unbalanced input options to the cartridge, making it a highly flexible device for integrating high-quality turntables into Chord systems. The comprehensive settings options are all externally selectable, with selections signified internally with illuminating LEDs.
